The MOTOTRBO R5 features loud, clear audio output up to 101 phons maximum loudness by default with a user programmable extra loud profile up to 106 phons. Its AI-trained noise suppression removes background sounds in noisy environments to improve intelligibility and long battery life up to 32 hours means workers can power through a full shift on one charge.
R5 has built-in Bluetooth 5.2 for wireless connection to accessories and Wi-Fi for remote updates and reprogramming. Like all MOTOTRBO radios, R5 has been built for durability and longevity: both waterproof and dust-tight, it’s built to withstand the harsh conditions found in the workplace.
Motorola R5 radio highlights
- Digital and analog transmissions
- 64 channels (non-display model) or 256 channels (display model)
- UHF and VHF frequency bands available
- 4 watts (UHF) and 5 watts (VHF) power output
- Up to 32 hours of battery life
- Bluetooth 5.2
- Loudness levels up to 106 phons
- Intrinsically Safe (UL Rated) option available
- IP67 waterproof and dust-proof
- 4 programmable buttons (display model) + Emergency button
- 2 programmable buttons (non-display model) + Emergency button
- 5 year Motorola warranty
Motorola R5 Model numbers
UHF - AAH07RDC9SA1AN (Non-Display)
UHF - AAH07RDH9SA1AN (Display)
VHF - AAH07JDC9SA1AN (Non-Display)
VHF - AAH07JDH9SA1AN (Display)
Motorola R5 Supported system technologies
- Conventional analog/digital
- IP Site Connect (optional add-on)
- Capacity Plus Single Site (optional add-on)
- Capacity Plus Multi Site (optional add-on)
Motorola R5 Standard Accessories
| Battery |
PMNN4888 2200 mAh Li-ion IMPRES |
| Charger |
PMPN4576 IMPRES |
| Antenna |
UHF - PMAE4079 (403-512 MHz)
VHF - PMAD4147 ( 136-174 MHz)
|
| Belt Clip |
PMLN7008
|
| Accessory Dust Cover |
0104058J40 |
| Warranty |
5 Years |
Motorola R5 Downloads
Spec Sheet | MOTOTRBO Brochure
Free radio programming included with purchase
Motorola two-way radios arrive from the manufacturer with no programming. This means they will not work with your existing radios, and even each other (assuming you buy 2 or more), until we make them. Your sales rep can guide you through your specific radio programming needs at no additional cost (at time of purchase).
